Артикул:
Stock #86-820
Нашли дешевле?
Характеристики
Numerical Aperture NA
—
0.75
Type
—
Microscope Objective
Wavelength Range (nm)
—
380 - 900
Manufacturer
—
Olympus
Mounting Threads
—
RMS / 20.32mm x 36 TPI
Model Number
—
1-U2B5272
Все характеристики
Цена действительна только для интернет-магазина и может отличаться от цен в розничных магазинах
Learn More
Product Family Description
- Ideal for Brightfield, Darkfield, DIC, Fluorescence, or Polarization Microscopy
- Excellent Transmission in the UV
- High Numerical Apertures and Oil Immersion Options Available
- Additional Olympus Infinity Corrected Objectives Available
Olympus Plan Fluorite Objectives are multi-purpose objectives that utilize advanced multi-coatings to provide excellent flat field images from the UV to NIR. Offering high signal-to-noise ratios, excellent resolution, and high contrast imaging capability, Olympus Plan Fluorite Objectives are ideal for brightfield microscopy or Nomarski differential interference contrast (DIC) observations, in addition to darkfield or fluorescence microscopy, or specific polarization techniques.
Документы
Numerical Aperture NA
0.75
Type
Microscope Objective
Wavelength Range (nm)
380 - 900
Manufacturer
Olympus
Mounting Threads
RMS / 20.32mm x 36 TPI
Model Number
1-U2B5272
Weight (g)
118
Focal Length FL (mm)
4.50
Working Distance (mm)
0.51
Maximum Diameter (mm)
26
Style
Infinity Corrected
Magnification
40X
Length excluding Threads (mm)
44.4
Compatible Tube Lens Focal Length (mm)
Focal Length: 180mm
Compatible Cover Glass Thickness (mm)
0.17
Depth of Field (μm)
0.49
Parfocal Length (mm)
45
Resolving Power (μm)
0.45
Immersion Liquid
N/A
Field Number (mm)
26.5
Отзывы
Оставить отзыв
Загрузка отзывов...
Technical Information
| Stock # | A | B | C | D | E | F | G | |
| UPLFLN 4X | 86-817 | 27.9 | 2.8 | 0.0 | 18.0 | 18.0 | 24.0 | 4.5 |
| UPLFLN 10X | 86-818 | 34.9 | 10.1 | 0.0 | 13.6 | 13.6 | 24.0 | 4.5 |
| UPLFLN 20X | 86-819 | 42.8 | 5.3 | 2.3 | 9.4 | 15.8 | 26.0 | 4.5 |
| UPLFLN 40X | 86-820 | 44.4 | 5.1 | 4.0 | 8.5 | 16.0 | 26.0 | 4.5 |
| UPLFLN 60X | 86-822 | 44.7 | 5.2 | 2.7 | 8.6 | 17.0 | 29.0 | 4.7 |
| UPLFLN 100X (Oil Immersion) | 86-823 | 44.7 | 5.5 | 3.0 | 7.0 | 17.2 | 28.0 | 4.5 |
 |
||||||||
